About the product
PCB Connector from OUPIIN
For socket reel 1001…CY1
According to DIN41651
Selective gold plating
With short or long levers
Pitch: 2.54mm
No of poles: 10, 14, 16, 20, 26, 34, 40, 50, 60, 64
Further, unpublished products and versions from OUPIIN on request.
Technical data
- Contact material: CuZn
- Insulating body: PBT UL94V-0
- Colour: Grey
- Contact resistance: 20 mOhm
- Insulating resistance: 5000 M Ohm
- Cycles: 100 min.
- Rated current: 1A / contact
- Temperature range: -55°C…+125°C
- Contact surface: Au/Ni
Technical changes reserved
Product specifications
| Manufacturer | OUPIIN |
| Nominal voltage (V) | 250 V |
| Contact pitch | 2,54 mm |
Data sheets
