About the product
IRM-20-12 is a compact 20W AC/DC power supply for direct PCB mounting.
The power supply module covers an input range of 85 to 305Vac and is constructed in a flame-retardant plastic housing.
Technical data
- Universal AC input 85 to 264Vac
- No load power consumption <0.1W
- Compact size
- Isolation class II unit (without earth pin)
- Protection: short circuit, overload and overvoltage
- Dimension 52.4 x 27.2 x 24mm (L x W x D)
- 3 years warranty
- Manufacturer: MEAN WELL
Product specifications
| Output voltage (VDC) | 12 V |
| Manufacturer warranty | 3 years |
| Manufacturer | MEAN WELL |
| Certificates | EN62368-1 / ITE, UL62368-1 / ITE |
| Input voltage range (VAC) | 85-305 V |
| Height | 24 mm |
| Width | 27.2 mm |
| Length | 52.4 mm |
| Application | ITE/AV |
| Power | 21 W |
| Efficiency | 84.00% |
Data sheets
