About the product
IRM-60-24 is a compact 60W AC/DC power supply for direct PCB mounting.
The power supply module covers an input range from 85 to 305Vac and is constructed in a flame-retardant plastic housing.
Technical data
- Universal AC input 85 to 264Vac
- No load power consumption <0.1W
- Compact size
- Isolation class II unit (without earth pin)
- Protection: short circuit, overload and overvoltage
- Dimension 87 x 52 x 29.5mm (L x W x D)
- 3 years warranty
- Manufacturer: MEAN WELL
Product specifications
| Output voltage (VDC) | 24 V |
| Manufacturer warranty | 3 years |
| Manufacturer | MEAN WELL |
| Certificates | EN60335-1 / Household, EN62368-1 / ITE, OVC III, UL62368-1 / ITE |
| Input voltage range (VAC) | 85-305 V |
| Height | 29.5 mm |
| Width | 52 mm |
| Length | 87 mm |
| Application | Household, ITE/AV |
| Power | 60 W |
| Efficiency | 90.00% |
