About the product
HLG-185H-24A is a robust 185W LED AC/DC converter with a very long life and high efficiency. Fully moulded and integrated in a metal housing, the LED driver is protected to IP65, making it ideal for both indoor and outdoor applications.
On the "A" version, voltage and current can be adjusted on the LED converter.
Vo ADJ. to correct voltage drop on long cables
Io ADJ. for setting maximum brightness
Technical data
- Universal AC input 90 to 305Vac
- CC/CV circuit for constant voltage and constant current applications
- Output voltage and constant current level can be adjusted through internal potentiometer
- IP65 for indoor and outdoor installations
- High reliable driver with long lifetime
- Fully encapsulated metal housing
- Suitable for dry, damp, and wet location
- Type HL LED driver for use in class I, division 2 hazardous location luminaires
- Meet 4kV surge immunity level (IEC61000-4-5)
- Dimension 228 x 68 x 38.8mm (L x W x H)
- 7 years warranty
- Manufacturer MEAN WELL
Product specifications
| Output voltage (VDC) | 24 V |
| Manufacturer warranty | 7 years |
| Product series | HLG |
| Input voltage range (VAC) | 100-277 V |
| Additional functions | Current/voltage setting on unit |
| Connection | Cable |
| IP protection | IP65 |
| Height | 38.8 mm |
| Width | 68 mm |
| Length | 228 mm |
| Application | Single color |
| Control | Non-dimmable |
| Channels | 1 |
| Output current | 7.8 A |
| Power | 185 W |
| Manufacturer | MEAN WELL |
