About the product
- BUS+FADER+DIMMER+DRIVER
- DC input 12-24 Vdc
- BUS command:
. - DALI - MULTI INPUT - Analog Automatic detection of the local command:
. - Normally open push button
. - 0-10V
. - 1-10V
. - Potentiometer 10KOhm - PUSH MENU' - option for setting:
. - Minimum dimming value
. - Fade in
. - Fade out - Constant voltage variant for common anode applications
- Voltage outputs for R loads DLM1224-1CV DALI
- Memory function
- Adjusting the brightness of white light or monochromatic colors
- Adjusting the brightness up to complete switch-off
- Soft start and soft stop
- Optimized output curve
- Typical efficiency > 95%
- 100% function test
- 5 year guarantee
Product specifications
| Application | Single color |
| Control | Low Voltage Push, Phase dimmer |
| Manufacturer's warranty | 5 years |
| IP protection | IP20 |
| Length | 45 mm |
| Width | 58 mm |
| Output current per channel (A) | 0.8 |
| Manufacturer | DalcNet |
| Height | 25 mm |
| Connection | Screw terminal |
| Channels | 1 |
| Product series | DAC |
