6000-R

Small details often have great effects. The crafted profile of the 6000-R is cut to renew the urban experience.

Product advantages

• Installation from 4m
• Reversible fixation top/side D60
• Adjustable luminaire tilt in top: 0°, 5° and 10°
• Adjustable luminaire tilt in side mounting: 0°, -5° and -10° from the bracket arm
• Colour temperature: 4000K, 3000K, 2700K, 2200K and Amber
• 5 choices of opticals, pedestrian included
• Pre-cabled luminaire
• Baked polyester powder coating
• Smart Lum options for energy savings
• PIR sensor
• Zhaga standard LED module
• Zhaga connector in option

Dimensions

Top view

• Length of the top of the lamp with mount is 650 mm
• Width of the top of the lamp with mount is 372 mm

Side view

• Length of the top of the lamp with mount is 200 mm
• Length of the top of the lamp without mount is 80 mm

RANGE

• Luminaire power range: from 19W to 107W
• Outgoing luminaire flux: from 2163 lm to 11588 lm at 4000K
• At 3000K, flux decreased by 6%.
• Life span L80B10 @350mA @tq=25°C ≥ 120,000h.
• Fewer than 10% of LEDs have an outgoing flux inferior to 80% of the initial flux at 120,000h.
• Thermal management of LED by sensor according to driver.

5 OPTICALS AVAILABLE

• ASYM 2
• ASYM 3
• ASYM 3.1
• ASYM 4
• Pedestrian optics

MATERIALS - SURFACE TREATMENT

• Body: die-cast aluminum
• Bowls: flat tempered glass
• Choice of RAL colors
• Baked (220°C) polyester powder coating
• Optional treatment specifically for coast/shoreline

MOUNTING – CABLING

• Reversible top/side fixation
• Top mounting on column Ø60-62mm with 0°, 5°, and 10° tilt or side mounting on tubular bracket Ø60-62 mm 90 mm length with 0°, -5°, and -10° negative tilt relative to the bracket.
• 10 available meter pre-cabled luminaire (flexible cable 2x 1.5mm²)

INSTALLATION – MAINTENANCE

• Captive screws’ opening. Replaceable driver.
• Replaceable LED module.

RESISTANCE TO OVERVOLTAGE

• Category IV luminaire, holding to a shock wave of 6kV between phase-neutral and earth.
• Protection against lightning 10kV-5kA between phase-neutral and earth to be provided at the base of the pole.
