About the product
120W DC/DC-Converter, Input 33.6…67.2V, Output 24V/5A
Technical data
- Compliance to EN50155 and EN45545-2
- Width only 32mm
- 2:1 wide input range
- -40°C until +70°C wide working temperature
- 150% peak load
- DC Output adjustable
- Cooling by free air convection
- For DIN Rail TS-35/7.5 or 15
- Protections: Short circuit/Overload/Over voltage/Input reverse polarity/Input under voltage
- 4KVdc I/O Reinforced Isolation
- 3 years warranty
- Manufacturer Mean Well
Product specifications
| Output voltage (VDC) | 24 V |
| Depth | 102 mm |
| Manufacturer | MEAN WELL |
| Application | ITE/AV, Railway |
| Height | 125.2 mm |
| Width | 32 mm |
| Additional functions | Peak Power |
| I/O isolation | 4000 V DC |
| Input voltage ratio | N/A |
| Input voltage range (VDC) | 33.6-67.2 V |
| Nominal input voltage (VDC) | 36-48 V |
| Output current | 5000 mA |
| Power | 120 W |
| Manufacturer warranty | 3 years |
