Techno 2-hole grommet for cable glands SW24, Ø 16.3 x 9.8 mm for Ø 4.5-5.5 mm

2-hole seal/grommet for various plugs with cable glands from Techno, Italy with wrench size 24 mm
. Feed-through grommet for the use of 2 cables with outer diameter Ø 4.5-5.5 mm

Dimensions: Ø 16.3 x 9.8 mm
Inner diameter/for cable diameter: Ø 4.5-5.5 mm

For other multi-hole gaskets and reducing sleeves from Techno and compatibility, see data sheets

Other, unpublished Techno products and designs on request.

Technical data

Dimensions: Ø 16.3 x 9.8 mm
for cable diameter: 2x Ø 4.5-5.5 mm
Color: Techno green
Cable glands: 2
Temperature range: -40°.. +100°C
Material: TPE

Subject to errors and technical changes
