Item ID: 41403.13051
Rim 70 Ceiling Painted 3070C/NRCCWB-Ceiling Recessed - Recessed with painted steel ring nut Ø70 - Remote driver max 500mA
About the product
Rim, the latest addition to the Augenti collection, is a small but performing recessed fixture with painted steel ring, proposed with diameters of 45 mm and 70 mm. The reduced sizes and the easy and quick installation allow its positioning in external and internal areas. In fact, Rim can be installed on floor, wall or ceiling, turning almost invisible, but insuring the created light and atmosphere to be the real main characters of the scene. The proposed beams are suitable for smooth or highlighted effects, for single or in-series installations. The ring of 316L stainless steel and the system AcquaStop for the anti-condensation protection make Rim a safe and multipurpose product, ideal to give light to your fantasy.
Product specifications
| Assembly | ceiling installation |
| Source flux | 750 lm |
| Fixture source | 535 lm |
| Apparent efficiency | 71.00% |
| Insulation class | class III |
| Operating Ta | -20°C to +50°C |
| CCT LED | 4000K |
| CRI | 80 CRI |
| MacAdam step | 3 |
| TM-21 lifespan | L80B10 80000h Ta 25°C |
| Optical distribution | PMMA lens |
| Source | LED |
| Absorbed power | 6 W |
| Control | remote DALI dimmable |
| Protection | IP67/IK08 |
| Body | anticorodal aluminum 6000 series, high corrosion resistance |
| Box | polypropylene (PP) 30% fiber UV-stabilized GWT750 |
| Frame | painted steel AISI316L |
| Screen | transparent extra-clear glass 8mm |
| Seals | Closed-cell EPDM rubber |
| Paint/Finishing | UV-stabilized anti-corrosive polyester powder |
| Size | H 70 x Ø 70 mm |
| Power supply | 500 mA max |
| Driver | remote driver not included |
| Beam opening | wide flood/36° |
