About the product
9W DC/DC-Converter, Input 9…18V, Output +/-12V / +/-0.375A
Technical data
- SIP8 package with international standard pinout
- 2:1 wide input range
- Operating temperature range -40°…+90°C
- No minimum load required
- High efficiency 89%
- Protection : continuous short circuit/Overload/Input under voltage
- 1.5kVdc I/O Isolation
- Remote ON/OFF
- 9V Output optional available
- 3 years warranty
- Manufacturer MEAN WELL
Product specifications
| Output voltage (VDC) | 12 V |
| Manufacturer | MEAN WELL |
| Application | ITE/AV |
| Height | 11.1 mm |
| Width | 9.2 mm |
| Length | 21.8 mm |
| Package / case | SIP8 |
| Additional functions | Remote ON/OFF |
| Regulation | Regulated |
| I/O isolation | 1500 V DC |
| Input voltage ratio | N/A |
| Input voltage range (VDC) | 9-18 V |
| Nominal input voltage (VDC) | 12-15 V |
| Output current | 375 mA |
| Power | 9 W |
| Manufacturer warranty | 3 years |
