About the product
90W LED Driver CV+CC 12V/7.5A
Technical data
- Universal AC input 90 to 305Vac
- No load power consumption <0.15W
- CC/CV circuit for constant voltage and constant current applications
- Fully isolated plastic case with IP67 level
- Class II power unit, without FG
- Dimension 171 x 63 x 37.5mm (L x W x H)
- 5 years warranty
- Manufacturer MEAN WELL
Product specifications
| Output voltage (VDC) | 12 V |
| Manufacturer warranty | 5 years |
| Product series | NPF |
| Input voltage range (VAC) | 100-277 V |
| Connection | Cable |
| IP protection | IP67 |
| Height | 37.5 mm |
| Width | 63 mm |
| Length | 171 mm |
| Application | Single color |
| Control | Non-dimmable |
| Channels | 1 |
| Output current | 7.5 A |
| Power | 90 W |
| Manufacturer | MEAN WELL |
