About the product
75W LED Driver CV+CC, 15V/5A, 3in1 Dimming
Technical data
- Universal AC input 90 to 305Vac
- CC/CV circuit for constant voltage and constant current applications
- Constant current level can be adjusted through 1-10Vdc / PWM signal or Resistance
- Fully isolated plastic case with IP67 level
- Class II power unit, without FG
- Dimension 161 x 61 x 36mm (L x W x H)
- 5 years warranty
- Manufacturer MEAN WELL
Product specifications
| Output voltage (VDC) | 15 V |
| Manufacturer warranty | 5 years |
| Product series | LPF |
| Input voltage range (VAC) | 100-277 V |
| Connection | Cable |
| IP protection | IP67 |
| Height | 36 mm |
| Width | 61 mm |
| Length | 161 mm |
| Application | Single color |
| Dimming method | Current regulation |
| Control | Resistor, 1-10V, PWM control signal |
| Channels | 1 |
| Output current | 5 mA |
| Power | 75 W |
| Manufacturer | MEAN WELL |
Data sheets
