About the product
75W DC/DC-Converter, Input 9.75V, Output 24V/3.12A
Technical data
- Efficiency 90%
- Fixed Switching Frequency
- Regulated Outputs
- Remote ON/OFF
- Low No Load Power Consumption
- Protection: Over Current/Over Voltaget/Over Temperature/Under Voltage Lockout
- 3000Vac I/O Isolation
- Operating Case Temperature -40°…+105°C
- Quarter Brick Size Meets Industrial Standard 2.28"x1.45"x0.5"
- CB Test Certificate IEC62368-1
- UL62368-1 2nd, Reinforce Insulation
- EN50155 Compliant with External Circuits
- Shock & Vibration EN50155 (EN61373) compliant
- Fire & Smoke EN45545-2 compliant
- 5000m Altitude
Product specifications
| Output voltage (VDC) | 24 V |
| Manufacturer | Cincon |
| Application | ITE/AV, Railway |
| Height | 12.7 mm |
| Width | 57.9 mm |
| Length | 36.8 mm |
| Package / case | Quarterbrick |
| Additional functions | Parallel connectable, Remote ON/OFF, Remote sense, Voltage Trim |
| Regulation | Regulated |
| I/O isolation | 3000 V DC |
| Input voltage ratio | N/A |
| Input voltage range (VDC) | 9-75 V |
| Nominal input voltage (VDC) | 12-72 V |
| Output current | 3120 mA |
| Power | 75 W |
| Manufacturer warranty | 3 years |
Data sheets
