About the product
75W DC/DC-Converter, Input 18…75V, Output +/-15V / +/-2.5A
Technical data
- 75W Isolated Output
- Efficiency 92.5%
- Low No Load Power Consumption
- 2.05’’x1.2×0.4’’ Six sided Shield Metal Case
- 4:1 Input Range
- Regulated Outputs
- Fixed Switching Frequency
- Protections: Over Current/Short circuit/Input Under Voltage
- Remote ON/OFF
- No Tantalum Capacitor Inside
- Safety Meets IEC/EN/UL62368-1
- Full Load Operation up to +54°C (included Heat Sink)
Product specifications
| Output voltage (VDC) | 15 V |
| Manufacturer | Cincon |
| Application | ITE/AV |
| Height | 10.2 mm |
| Width | 30.5 mm |
| Length | 52 mm |
| Package / case | 2.05x1.2 Inch |
| Additional functions | Remote ON/OFF, Voltage Trim |
| Regulation | Regulated |
| I/O isolation | 2250 V DC |
| Input voltage ratio | N/A |
| Input voltage range (VDC) | 18-75 V |
| Nominal input voltage (VDC) | 24-72 V |
| Output current | 2500 mA |
| Power | 75 W |
| Manufacturer warranty | 3 years |
