6W DC/DC-Converter, Input 18…75V, Output +/-12V / +/-0.25A
Technical data
- 24 Pin DIP Package, Full SMD Technology
- Wide 4:1 Input Range
- 1500Vdc Isolation
- Continuous Short Circuit Protection
- Efficiency up to 81%
- Operation Temperature Range -40°C to +85°C
- EMC Filter meets EN55032 Class A without adding external components
- Non-Conductive Black Plastic Case
- Dimension 31.75 x 20.32 x 10.16mm (L x W x H)
Product specifications
| Output voltage (VDC) | 12 V |
| Manufacturer | Motien |
| Application | ITE/AV |
| Height | 10.16 mm |
| Width | 20.32 mm |
| Length | 31.75 mm |
| Package / case | DIP24 |
| Regulation | Regulated |
| I/O isolation | 1500 V DC |
| Input voltage ratio | N/A |
| Input voltage range (VDC) | 18-75 V |
| Nominal input voltage (VDC) | 24-72 V |
| Output current | 250 mA |
| Power | 6 W |
| Manufacturer warranty | 3 years |
