About the product
6.6W DC/DC-Converter, Input 18…75V, Output 3.3V/2A
Technical data
- Compliance with EN50155 railway standard
- DIP 24 package with standard pinout
- 4:1 wide input range
- Wide operating temperature range -40 ~ +85°C
- No minimum load required
- Full encapsulated
- Protections: Short circuit/Overload/Over voltage/Input under voltage
- 1.5KVdc I/O Isolation
- Remote ON/OFF control
- 3 years warranty
- Manufacturer: MEAN WELL
Product specifications
| Output voltage (VDC) | 3.3 V |
| Manufacturer | MEAN WELL |
| Application | ITE/AV, Railway |
| Height | 10.2 mm |
| Width | 20.3 mm |
| Length | 31.8 mm |
| Package / case | DIP24 |
| Additional functions | Remote ON/OFF |
| Regulation | Regulated |
| I/O isolation | 1500 V DC |
| Input voltage ratio | N/A |
| Input voltage range (VDC) | 18-75 V |
| Nominal input voltage (VDC) | 24-72 V |
| Output current | 2000 mA |
| Power | 6.6 W |
| Manufacturer warranty | 3 years |
