About the product
4.95W PCB Mount Power Supply encapsulated 3.3V/1.5A
Technical data
- Universal AC Input 90 to 264Vac
- No Load Input Power 75mW
- Class II
- High Efficiency 83%
- Approved EN55032 Class B and CISPR/FCC Class B
- Approved IEC62368-1, UL62368-1, EN62368-1
- Meets EN61558 (EN60335)
- Protection: Continuous Short Circuit and Over Voltage
Product specifications
| Output voltage (VDC) | 3.3 V |
| Manufacturer warranty | 3 years |
| Manufacturer | Cincon |
| Certificates | EN62368-1 / ITE, UL62368-1 / ITE |
| Input voltage range (VAC) | 90-264 V |
| Height | 20 mm |
| Width | 21 mm |
| Length | 41.1 mm |
| Application | Household, ITE/AV |
| Power | 5 W |
| Efficiency | 75.00% |
Data sheets
