About the product
40W LED Driver with PWM Output 12V/3.34A
Technical data
- Universal AC input 90 to 305Vac
- Constant voltage output
- Built-in 3in1 dimming function (0-10V / PWM Signal / Resistance)
- PWM style dimming
- No load power consumption <0.5W
- Fully isolated plastic case with IP67 level
- Class II power unit, without FG
- Dimension 150 x 53 x 35mm (L x W x H)
- 5 years warranty
- Manufacturer MEAN WELL
Product specifications
| Output voltage (VDC) | 12 V |
| Manufacturer warranty | 5 years |
| Product series | PWM |
| Input voltage range (VAC) | 100-277 V |
| Connection | Cable |
| IP protection | IP67 |
| Height | 35 mm |
| Width | 53 mm |
| Length | 150 mm |
| Application | Single color |
| Dimming method | PWM |
| Control | Resistor, 0-10V, 1-10V, PWM control signal |
| Channels | 1 |
| Output current | 3.34 A |
| Power | 40 W |
| Manufacturer | MEAN WELL |
Data sheets
