About the product
40W LED Driver CV+CC 20V/2A
Technical data
- Universal AC input 90 to 305Vac
- No load power consumption <0.15W
- CC/CV circuit for constant voltage and constant current applications
- Fully isolated plastic case with IP67 level
- Class II power unit, without FG
- Dimension 150 x 53 x 35mm (L x W x H)
- 5 years warranty
- Manufacturer MEAN WELL
Product specifications
| Output voltage (VDC) | 20 V |
| Manufacturer warranty | 5 years |
| Product series | NPF |
| Input voltage range (VAC) | 100-277 V |
| Connection | Cable |
| IP protection | IP67 |
| Height | 35 mm |
| Width | 53 mm |
| Length | 150 mm |
| Application | Single color |
| Control | Non-dimmable |
| Channels | 1 |
| Output current | 2 mA |
| Power | 40 W |
| Manufacturer | MEAN WELL |
