About the product
3W medical DC/DC-Converter, Input 18…75V, Output +/-12V / +/- 0.125
Technical data
- Wide Input range 2:1/4:1
- IEC/EN60601-1 (2 x MOOP) approved
- Insulation Voltage 3kVac
- Low No load power consumption
- Low Leakage current
- Protection: Overcurrent / Over voltage / Short circuit / Under voltage
- EMI EN55032 class A
- 5 years warranty
- Manufacturer P-Duke
Product specifications
| Output voltage (VDC) | 12 V |
| Manufacturer | P-Duke |
| Application | ITE/AV, Medical |
| Height | 10.2 mm |
| Width | 20.9 mm |
| Length | 32.4 mm |
| Package / case | DIP24 |
| Additional functions | Remote ON/OFF, Voltage Trim |
| Regulation | Regulated |
| I/O isolation | 3000 V AC |
| Input voltage ratio | N/A |
| Input voltage range (VDC) | 18-75 V |
| Nominal input voltage (VDC) | 24-72 V |
| Output current | 125000 mA |
| Power | 3 W |
| Manufacturer warranty | 5 years |
Data sheets
