About the product
3W medical DC/DC converter, input 18..36V, output +/-12V / +/- 0.125
Technical data
- Wide input voltage range 2:1/4:1
- IEC/EN60601-1 (2 x MOPP) approved
- Reinforced insulation voltage 5kVac
- Low no-load current consumption
- Deep leakage current
- Protective circuit: overcurrent / overvoltage / short circuit / undervoltage
- EMI EN55032 class A
- 5 year guarantee
- Manufacturer P-Duke
Product specifications
| Power | 3 W |
| Design | DIP24 |
| Additional functions | Remote ON/OFF, Voltage Trim |
| Manufacturer | P-Duke |
| Width | 20.9 mm |
| Length | 32.4 mm |
| Output current | 125000 mA |
| Height | 10.2 mm |
| Nominal input voltage (VDC) | 24 V |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Output voltage (VDC) | 12 V |
| Application | ITE/AV, Medical |
| I/O isolation | 5000 VAC |
