About the product
3W DC/DC-Converter, Input 4.5…18V, Output +/-15V / +/-0.1A
Technical data
- 8 Pin DIP Package, Full SMD Technology
- Wide 4:1 Input Range
- 1600Vdc Isolation
- Continuous Short Circuit Protection
- Efficiency up to 82%
- Operation Temperature Range -40°C to +85°C
- Remote On/Off
- Dimension 31.75 x 20.32 x 10.16mm (L x W x H)
- 3 years warranty
- Manufacturer Motien
Product specifications
| Output voltage (VDC) | 15 V |
| Manufacturer | Motien |
| Application | ITE/AV |
| Height | 11.1 mm |
| Width | 9.2 mm |
| Length | 21.85 mm |
| Package / case | SIP8 |
| Additional functions | Remote ON/OFF |
| Regulation | Regulated |
| I/O isolation | 1600 V DC |
| Input voltage ratio | N/A |
| Input voltage range (VDC) | 4.5-18 V |
| Nominal input voltage (VDC) | 5-15 V |
| Output current | 100000 mA |
| Power | 3 W |
| Manufacturer warranty | 3 years |
Data sheets
