About the product
3W DC/DC-Converter, Input 36…75V, Output +/-15V / +/-0.1A
Technical data
- Wide Input Range 2:1
- Full SMD Technology
- 1500Vdc Isolation, Option up to 3000Vdc
- Protecion : Short circuit
- Efficiency 81%
- -40°.+85°C Operating Temperature Range
- EMC filter meets EN55032 Class A without external components
- Non-conductive black plastic DIP24 case
- 3 Years Warranty
- Manufactuer Motien
Product specifications
| Output voltage (VDC) | 15 V |
| Manufacturer | Motien |
| Application | ITE/AV |
| Height | 10.16 mm |
| Width | 20.32 mm |
| Length | 31.75 mm |
| Package / case | DIP24 |
| Regulation | Regulated |
| I/O isolation | 1500 V DC |
| Input voltage ratio | N/A |
| Input voltage range (VDC) | 36-75 V |
| Nominal input voltage (VDC) | 48-72 V |
| Output current | 100000 mA |
| Power | 3 W |
| Manufacturer warranty | 3 years |
