About the product
3W DC/DC-Converter, Input 18…75V, Output 12V/0.25A
Technical data
- 4:1 wide Input range
- DIP24 package with standard pinout
- 6000Vdc or 4.2Vac Isolation (Reinforced isolation)
- Low Leakage current <5müA
- Protection: continuous short circuit, Overload
- Wide operation temperature range -40°C…+90°C
- Medical safety approved (2xMOPP) according to IEC60601-1
- 3 years warranty
- Manufacturer MEAN WELL
Product specifications
| Output voltage (VDC) | 12 V |
| Application | Medical |
| Height | 12.2 mm |
| Width | 20.3 mm |
| Length | 31.8 mm |
| Package / case | DIP24 |
| Regulation | Regulated |
| I/O isolation | 6000 V DC |
| Input voltage ratio | N/A |
| Input voltage range (VDC) | 18-75 V |
| Nominal input voltage (VDC) | 24-72 V |
| Output current | 250 mA |
| Power | 3 W |
| Manufacturer | MEAN WELL |
