About the product
3W DC/DC-Converter, Input 18…75V, Output 12V/0.25A
Technical data
- Wide 4:1 Input Range
- 1600Vdc Isolation
- Efficiency 84%
- Extended Operating Temperature Range -40° to +80°C
- Remote On/Off Control (CTRL)
- Continuous Short Circuit Protection
- Under Voltage Lock Out Circuit
- 3 years warranty
- Manufacturer Motien
Product specifications
| Output voltage (VDC) | 12 V |
| Manufacturer | Motien |
| Application | ITE/AV |
| Height | 8.1 mm |
| Width | 14.8 mm |
| Length | 14 mm |
| Package / case | DIP8 |
| Additional functions | Remote ON/OFF |
| Regulation | Regulated |
| I/O isolation | 1600 V DC |
| Input voltage ratio | N/A |
| Input voltage range (VDC) | 18-75 V |
| Nominal input voltage (VDC) | 24-72 V |
| Output current | 250 mA |
| Power | 3 W |
| Manufacturer warranty | 3 years |
Data sheets
