About the product
3W DC/DC-Converter, Input 18…36V, Output 12V/0.25A
Technical data
- DIP24 package with industry standard pinout
- 2:1 wide input range
- Operating Temperature Range -40°C to +90°C
- No minimum load required
- Comply to EN55032 radiated class A without additional components
- High efficiency up to 87%
- Protection : Continuous Short circuit / Overload / Input under voltage
- 3kVdc I/O Isolation
- 3 years warranty
- Manufacturer Mean Well
Product specifications
| Output voltage (VDC) | 12 V |
| Manufacturer | MEAN WELL |
| Application | ITE/AV |
| Height | 10.2 mm |
| Width | 20.3 mm |
| Length | 31.8 mm |
| Package / case | DIP24 |
| Regulation | Regulated |
| I/O isolation | 3000 V DC |
| Input voltage ratio | N/A |
| Input voltage range (VDC) | 18-36 V |
| Nominal input voltage (VDC) | 24 V |
| Output current | 250 mA |
| Power | 3 W |
| Manufacturer warranty | 3 years |
Data sheets
