About the product
33W DC/DC-Converter, Input 9…36V, Output 3.3V/10A
Technical data
- 40W Isolated Output
- Efficiency 91%
- Six-Sided Shield Metal Case
- 4:1 Input Range
- Regulated Outputs
- Protection: Input Under Voltage Protection/Over Current/Short Circuit
- Remote On/Off
- Low No Load Power Consumption
- Shock & vibration meets EN50155 (EN61373)
- Dimension 52 x 30.5 x 10.2mm (L x W x H)
Product specifications
| Output voltage (VDC) | 3.3 V |
| Manufacturer | Cincon |
| Application | ITE/AV, Railway |
| Height | 10.2 mm |
| Width | 30.5 mm |
| Length | 52 mm |
| Package / case | 2.05x1.2 Inch |
| Additional functions | Remote ON/OFF, Voltage Trim |
| Regulation | Regulated |
| I/O isolation | 3000 V DC |
| Input voltage ratio | N/A |
| Input voltage range (VDC) | 9-36 V |
| Nominal input voltage (VDC) | 12-24 V |
| Output current | 10000 mA |
| Power | 33 W |
| Manufacturer warranty | 3 years |
Data sheets
