About the product
30W DC/DC-Converter, Input 18…75V, Output +/-15V / +/-1A
Technical data
- Ultra Wide 4:1 Input Range
- 1600Vdc Isolation
- No Minimum Load Required
- Efficiency up to 92%
- Extended Operating Temperature Range -40°C to +100°C
- Adjustable Output Voltage
- Remote On/Off Control (CTRL)
- Continuous Short Circuit Protecion
- Over Current Protection
- Over Voltage Protection
- Over Temperature Protection
- 3 Years Warranty
- Manufacturer Motien
Product specifications
| Output voltage (VDC) | 15 V |
| Manufacturer | Motien |
| Application | ITE/AV |
| Height | 10.4 mm |
| Width | 25.4 mm |
| Length | 25.4 mm |
| Package / case | 1x1 Inch |
| Additional functions | Remote ON/OFF, Voltage Trim |
| Regulation | Regulated |
| I/O isolation | 1600 V DC |
| Input voltage ratio | N/A |
| Input voltage range (VDC) | 18-75 V |
| Nominal input voltage (VDC) | 24-72 V |
| Output current | 1000 mA |
| Power | 30 W |
| Manufacturer warranty | 3 years |
