About the product
2W DC/DC-Converter, Input 10.8…13.2V, Output +/-5V / +/-0.2A
Technical data
- 7 Pin SIL Package
- 5200Vdc High Isolation
- Low Ripple and Noise
- Efficiency up to 85%
- Long term short circuit protection
- -40°C…90°C Operation Temperatur Range
- Low coupling capacitance
- Dedicated for IGBT applications
- 3 years warranty
- Manufacturer Motien
Product specifications
| Output voltage (VDC) | 5 V |
| Manufacturer | Motien |
| Application | ITE/AV |
| Height | 10 mm |
| Width | 7.2 mm |
| Length | 19.5 mm |
| Package / case | SIP7 |
| Regulation | Unregulated |
| I/O isolation | 5200 V DC |
| Input voltage ratio | +/-10 % |
| Input voltage range (VDC) | 10.8-13.2 V |
| Nominal input voltage (VDC) | 12 V |
| Output current | 200000 mA |
| Power | 2 W |
| Manufacturer warranty | 3 years |
