2W DC/DC-Converter, Input 10.8…13.2V, Output 12V/0.167A
Technical data
- SIP7 package with industry standard pinout
- Operating temperature range -40°…+105°C
- Comply to EN55032 radiated class A without additional components
- High efficiency 87%
- Protections: Short circuit/Over current
- 3kVdc I/O Isolation
- Low cost
- 3 years warranty
- Manufacturer Mean Well
Product specifications
| Output voltage (VDC) | 12 V |
| Manufacturer | MEAN WELL |
| Application | ITE/AV |
| Height | 10.2 mm |
| Width | 7.2 mm |
| Length | 19.6 mm |
| Package / case | SIP7 |
| Regulation | Unregulated |
| I/O isolation | 3000 V DC |
| Input voltage ratio | +/-10 % |
| Input voltage range (VDC) | 10.8-13.2 V |
| Nominal input voltage (VDC) | 12 V |
| Output current | 167 mA |
| Power | 2 W |
| Manufacturer warranty | 3 years |
