About the product
26W DC/DC-Converter, Input 36…75V, Output 3.3V/8A
Technical data
- Wide 2:1 Input Range
- 1600 Vdc Isolation
- Efficiency up to 92%
- Extended Operating Temperature Range -40°C to +71°C
- Adjustable Output Voltage
- Remote On/Off Control (Ctrl)
- Continuous Short Circuit Protection
- Over Load Protection
- Over Voltage Protection
- High Power Density : 40Watt in 2x 1x 0.4 package
- No minimum Load Required
- Option Heat Sink
- 3 years warranty
- Manufacturer Motien
Product specifications
| Output voltage (VDC) | 3.3 V |
| Manufacturer | Motien |
| Application | ITE/AV |
| Height | 10.16 mm |
| Width | 25.4 mm |
| Length | 50.8 mm |
| Package / case | 2x1 Inch |
| Additional functions | Remote ON/OFF, Voltage Trim |
| Regulation | Regulated |
| I/O isolation | 1600 V DC |
| Input voltage ratio | N/A |
| Input voltage range (VDC) | 36-75 V |
| Nominal input voltage (VDC) | 48-72 V |
| Output current | 8000 mA |
| Power | 26 W |
| Manufacturer warranty | 3 years |
