240W LED Driver CV+CC 48V/5A, 3in1 Dimming + Vo/Io adjustable

Delivery at your place between May 21 and Jun 25 2025

Add to cart

About the product

ELG-240-48AB-3Y series is a combination of "A" and "B" type. Current and voltage is adjustable through built-in potentiometer and for external dimming the current level can be adjusted by built-in 3in1 dimming function

Technical data

100-305 Vac Input Range (De-rating may be needed under low input voltages)
Built-in active PFC Function
Output voltage and constant current level can be adjusted through internal potentiometer
Constant current level can be adjusted through 0-10Vdc / PWM signal or Resistance
IP65 Design
Meet 6kV Surge Immunity Level (IEC61000-4-5)
Fully encapsulated metal housing
Typical Lifetime 50’000h
Working Temperature -40°C to +70°C
Dimensions 244 x 71 x 37.5mm (L x W x H)
5 years warranty
Manufacturer: MEAN WELL

Product specifications

Output voltage (VDC)	48 V
Efficiency	92.00%
Manufacturer	MEAN WELL
Manufacturer warranty	5 years
Product series	ELG
Input voltage range (VAC)	110-277 V
Additional functions	Current/voltage setting on unit
Connection	Cable
IP protection	IP67
Height	37.5 mm
Width	71 mm
Length	244 mm
Application	Single color
Dimming method	Current regulation
Control	Resistor, 0-10V, 1-10V, PWM control signal
Channels	1
Output current	5 mA
Panel power	240 W
