About the product
20W PCB Mount Power Supply encapsulated 5V/4A
Technical data
- Universal AC Input 90 to 264Vac
- Efficiency 87%
- No Load Power Consumption <0.1W
- Protection: short circuit and over voltage
- Meets EN55032 Class B and CIRSS/FCC Class B
- Meets IEC62368-1, UL62368-1 and IEC/EN60335-1, IEC61558-1
- Industrial safety IEC/UL/EN60950-1
- Peak Power (2 times of Rated Power)
- Class II
- Dimension (Suffix -E) 53.1 x 30.3 x 24.8mm (L x W x H)
Product specifications
| Output voltage (VDC) | 5 V |
| Manufacturer warranty | 3 years |
| Manufacturer | Cincon |
| Certificates | EN60335-1 / Household, EN62368-1 / ITE, UL62368-1 / ITE |
| Input voltage range (VAC) | 90-264 V |
| Height | 24.8 mm |
| Width | 30.3 mm |
| Length | 53.1 mm |
| Application | Household, ITE/AV |
| Power | 20 W |
| Efficiency | 81.00% |
