About the product
20W DC/DC-Converter, Input 9…36V, Output 15V/1.33A
Technical data
- 20W Isolated Output
- Shielded Metal Case
- Efficiency 89%
- Lo now load power consumption
- 4:1 Input Range
- Regulated Outputs
- Protection: Input Under Voltage/Over Current/Short Circuit
- Remote On/Off
- Dimension 25.4 x 25.4 x 10.2mm (L x W x H)
Product specifications
| Output voltage (VDC) | 15 V |
| Manufacturer | Cincon |
| Application | ITE/AV |
| Height | 11.7 mm |
| Width | 25.4 mm |
| Length | 25.4 mm |
| Package / case | 1x1 Inch |
| Additional functions | Remote ON/OFF, Voltage Trim |
| Regulation | Regulated |
| I/O isolation | 1500 V DC |
| Input voltage ratio | N/A |
| Input voltage range (VDC) | 9-36 V |
| Nominal input voltage (VDC) | 12-24 V |
| Output current | 1333 mA |
| Power | 20 W |
| Manufacturer warranty | 3 years |
Data sheets
