About the product
20W DC/DC-Converter, Input 9…36V, Output +/-15V / +/-0.666A
Technical data
- Compliance with EN50155 Railway standard
- DIP 2x1 package with standard pinout
- 4:1 wide input range
- Wide operating temperarure range -40°C…+85°C
- No minimum load required
- Full encapsulated
- Protections: short circuit/Overload/Over voltage/Input under voltage
- 1.5kVdc/3kVdc Isolation by models
- Remote ON/OFF control
- 3 years warranty
- Manufacturer Mean Well
Product specifications
| Output voltage (VDC) | 15 V |
| Manufacturer | MEAN WELL |
| Application | ITE/AV, Railway |
| Height | 10.5 mm |
| Width | 25.4 mm |
| Length | 50.8 mm |
| Package / case | 2x1 Inch |
| Additional functions | Remote ON/OFF, Voltage Trim |
| Regulation | Regulated |
| I/O isolation | 1500 V DC |
| Input voltage ratio | N/A |
| Input voltage range (VDC) | 9-36 V |
| Nominal input voltage (VDC) | 12-24 V |
| Output current | 666 mA |
| Power | 20 W |
| Manufacturer warranty | 3 years |
