About the product
20W DC/DC-Converter, Input 9…36V, Output 12V/1.67A
Technical data
- Ultra Wide 4:1 Input Range
- 3000Vdc Isolation
- No Minimum Load Required
- Efficiency up to 91%
- Extended Operating Temperature Range -40°C to +100°C
- Adjustable Output Voltage
- Remote On/Off Control (Ctrl)
- Continuous Short Circuit Protection
- Over Current Protection
- Over Voltage Protection
- Built-In EMI Filter meets EN55032 class A without external components
- 3 years warranty
- Manufacturer Motien
Product specifications
| Output voltage (VDC) | 12 V |
| Manufacturer | Motien |
| Application | ITE/AV |
| Height | 10.4 mm |
| Width | 25.4 mm |
| Length | 40.64 mm |
| Package / case | 1.6 x 1 Inch |
| Additional functions | Remote ON/OFF, Voltage Trim |
| Regulation | Regulated |
| I/O isolation | 3000 V DC |
| Input voltage ratio | N/A |
| Input voltage range (VDC) | 9-36 V |
| Nominal input voltage (VDC) | 12-24 V |
| Output current | 1670 mA |
| Power | 20 W |
| Manufacturer warranty | 3 years |
Data sheets
