About the product
20W DC/DC-Converter, Input 18…75V, Output +/-12V / +/-0.83A
Technical data
- 20W Isolated Output
- Shielded Metal Case
- Efficiency 89%
- Lo now load power consumption
- 4:1 Input Range
- Regulated Outputs
- Protection: Input Under Voltage/Over Current/Short Circuit
- Remote On/Off
- Dimension 25.4 x 25.4 x 10.2mm (L x W x H)
Product specifications
Output voltage (VDC) | 12 V |
Manufacturer | Cincon |
Application | ITE/AV |
Height | 11.7 mm |
Width | 25.4 mm |
Length | 25.4 mm |
Package / case | 1x1 Inch |
Additional functions | Remote ON/OFF, Voltage Trim |
Regulation | Regulated |
I/O isolation | 1500 V DC |
Input voltage ratio | N/A |
Input voltage range (VDC) | 18-75 V |
Nominal input voltage (VDC) | 24-72 V |
Output current | 833 mA |
Power | 20 W |
Manufacturer warranty | 3 years |
Data sheets
