About the product
1W DC/DC-Converter, Input 4.5…9V, Output 12V/0.083A
Technical data
- Wide 2:1 Input Range
- 1500.3000Vdc Isolation
- Fully regulated Output
- No minimum Load required
- Continuous short circuit protection
- Efficiency up to 80%
- Low Ripple and Noise
- -40°.+90°C Operating Temperature Range
- 3 Years Warranty
- Manufacturer Motien
Product specifications
| Output voltage (VDC) | 12 V |
| Manufacturer | Motien |
| Application | ITE/AV |
| Height | 7.2 mm |
| Width | 10 mm |
| Length | 19.5 mm |
| Package / case | SIP7 |
| Regulation | Regulated |
| I/O isolation | 1500 V DC |
| Input voltage ratio | N/A |
| Input voltage range (VDC) | 4.5-9 V |
| Nominal input voltage (VDC) | 5 V |
| Output current | 84000 mA |
| Power | 1 W |
| Manufacturer warranty | 3 years |
