About the product
1W DC/DC-Converter, Input 4.5…5.5V, Output 15V/0.67A
Technical data
- SMD package with industry standard pinout
- Operating temperature -40°C to +90°C
- Comply to EN55032 radiated class B without additional components
- High efficiency up to 84%
- Short Circuit Protection
- 1.5kVdc I/O Isolation
- Low cost
- 3 years warranty
- Manufacturer Mean Well
Product specifications
| Output voltage (VDC) | 15 V |
| Manufacturer | MEAN WELL |
| Application | ITE/AV |
| Height | 7.1 mm |
| Width | 10.9 mm |
| Length | 12.9 mm |
| Package / case | SMD8 |
| Regulation | Unregulated |
| I/O isolation | 1500 V DC |
| Input voltage ratio | +/-10 % |
| Input voltage range (VDC) | 4.5-5.5 V |
| Nominal input voltage (VDC) | 5 V |
| Output current | 67000 mA |
| Power | 1 W |
| Manufacturer warranty | 3 years |
