About the product
16W LED Driver CV+CC 48V/0.34A
Technical data
- Universal AC input 90 to 305Vac
- CC/CV circuit for constant voltage and constant current applications
- Fully isolated plastic case with IP30 level for indoor installations
- Class II power unit, without FG
- Dimension 148 x 40 x 32mm (L x W x H)
- 5 Years Warranty
- Manufacturer MEAN WELL
Product specifications
| Output voltage (VDC) | 48 V |
| Manufacturer warranty | 5 years |
| Product series | LPF |
| Input voltage range (VAC) | 100-277 V |
| Connection | Cable |
| IP protection | IP30 |
| Height | 32 mm |
| Width | 40 mm |
| Length | 148 mm |
| Application | Single color |
| Control | Non-dimmable |
| Channels | 1 |
| Output current | 0.34 A |
| Power | 16 W |
| Manufacturer | MEAN WELL |
