About the product
15W DC/DC-Converter, Input 9…36V, Output 12V/1.25A
Technical data
- Width only 17.5mm (1SU)
- 4:1 ultra wide input range
- -40°C until +85°C wide working temperature
- No minimum load required
- DC Output adjustable (+/-10%)
- Cooling by free air convection
- For DIN Rail TS-35/7.5 or 15
- Protections: Short circuit/Overload/Over voltage/Input reverse polarity/Input under voltage
- 4KVdc I/O Reinforced Isolation
- 3 years warranty
- Manufacturer Mean Well
Product specifications
| Output voltage (VDC) | 12 V |
| Depth | 54.5 mm |
| Manufacturer | MEAN WELL |
| Application | ITE/AV |
| Height | 90 mm |
| Width | 17.5 mm |
| I/O isolation | 4000 V DC |
| Input voltage ratio | N/A |
| Input voltage range (VDC) | 9-36 V |
| Nominal input voltage (VDC) | 12-24 V |
| Output current | 1250 mA |
| Power | 15 W |
| Manufacturer warranty | 3 years |
Data sheets
