About the product
15W DC/DC Converter, Input 9…36V, Output 12V/1.25A
Technical data
- DIP package 1’’x1’’ with industrial standard pinout
- 4 :1 ultrawide input range
- High efficiency up to 89%
- Operating temperature range -40°…+85°C
- No minimum load required
- Comply to EN55032 radiated class A without additional component
- Protections : Continuous short circuit/Overload/Over voltage/Input under voltage lock-out
- 3kVdc I/O Isolation
- 3 years warranty
- Manufacturer Mean Well
Product specifications
| Output voltage (VDC) | 12 V |
| Manufacturer | MEAN WELL |
| Application | ITE/AV |
| Height | 11.7 mm |
| Width | 25.4 mm |
| Length | 25.4 mm |
| Package / case | 1x1 Inch |
| Additional functions | Remote ON/OFF, Voltage Trim |
| Regulation | Regulated |
| I/O isolation | 3000 V DC |
| Input voltage ratio | N/A |
| Input voltage range (VDC) | 9-36 V |
| Nominal input voltage (VDC) | 12-24 V |
| Output current | 1250 mA |
| Power | 15 W |
| Manufacturer warranty | 3 years |
