15W DC/DC-Converter, Input 18…36V, Output 15V/1A
Technical data
- DIP 2’’x1’’ package with international standard pinout
- 2:1 wide input range
- Low patient leakage current 5microAmp
- Wide operating temperature range -40°.+90°C
- Medical safety approved (2xMOPP) according to IEC60601-1
- No minimum load required
- Protections: continuous short circuit/overload/input under voltage
- 4000Vac IN/OUT Isolation (Reinforced Isolation)
- 3 years warranty
- Manufacturer Mean Well
Product specifications
| Output voltage (VDC) | 15 V |
| Manufacturer | MEAN WELL |
| Application | ITE/AV, Medical |
| Height | 12 mm |
| Width | 25.4 mm |
| Length | 50.8 mm |
| Package / case | 2x1 Inch |
| Regulation | Regulated |
| I/O isolation | 4000 V DC |
| Input voltage ratio | N/A |
| Input voltage range (VDC) | 18-36 V |
| Nominal input voltage (VDC) | 24 V |
| Output current | 1000 mA |
| Power | 15 W |
| Manufacturer warranty | 3 years |
