About the product
LS-150-24 LI is an 150W constant voltage LED Driver. The class II design (without FG) accepts input from 176 to 264Vac. Equipped with terminal block and strain relief LS-150-24 LI ideally fits the entry-level LED applications.
Technical data
- Input voltage 176 bis 264Vac
- Life Time >50’000 hours
- Operating temperature -20°C bis +40°C
- Dimensions 268 x 45 x 30.5mm (L x W x H)
- 5 years warranty
- Manufacturer: Eaglerise
Product specifications
| Output voltage (VDC) | 24 V |
| Manufacturer warranty | 5 years |
| Product series | LS |
| Input voltage range (VAC) | 200-240 V |
| Connection | Push-in terminal |
| IP protection | IP20 |
| Height | 30.5 mm |
| Width | 45 mm |
| Length | 268 mm |
| Application | Single color |
| Control | Non-dimmable |
| Channels | 1 |
| Output current | 6.25 A |
| Power | 150 W |
| Manufacturer | Eaglerise |
