About the product
The LED driver SLD-150-56 with only 35mm width and 22mm height is suitable for LED constant current applications. The proven constant power circuit with extended operating window allows the same power supply to be used in different luminaires.
Technical data
- Slim design, only 35mm wide and 22mm high
- Constant power circuit for extended operating range
- Protection class II unit without earth connection
- Connections with spring terminals
- Dimensions 330 x 35 x 22mm (L x W x H)
Product specifications
| Power | 150 W |
| Manufacturer warranty | 5 years |
| Manufacturer | MEAN WELL |
| Output current | 6.3 A |
| Input voltage range (VAC) | 120-305 V |
| Product series | SLD |
| Efficiency | 93.00% |
| Output current | 1400-4170 mA |
| Output voltage range (VDC) | 24-56 V |
| Additional functions | Constant power |
| Connection | Push-in terminal |
| Control | Non-dimmable |
| Channels | 1 |
| Current setting | Potentiometer |
| Application | Single color |
| Length | 330 mm |
| Width | 35 mm |
| Height | 22 mm |
| IP protection | IP20 |
| Packaging unit | 48 |
