About the product
HDR-150-12 is an ultra-compact DIN rail power supply for installation in distribution boards. Approved for industrial and domestic applications, the power supplies are the ideal solution for industrial control systems and building automation.
Technical data
- Suitable for mounting on TS-35/7.5/15 top-hat rails
- Haushaltszulassung EN61558-2-16
- Protection class II Device without earth connection
- LED display for DC OK
- Dimensions 105 x 90x 54.5mm (W x H x D)
Product specifications
| Manufacturer | MEAN WELL |
| Overload behaviour | Hiccup mode |
| Output current | 11.3 A |
| Power | 135 W |
| Width | 105 mm |
| Product series | HDR |
| Depth | 54.5 mm |
| Height | 90 mm |
| Input voltage range (VAC) | 85-264 V |
| Output voltage (VDC) | 12 V |
| Certificates | IEC62368-1, EAC TP TC 004, UL62368-1, EN61558-2-16, UL61010-1, OVC III |
