About the product
120W DIN Rail Power Supply 48V/2.5A
Technical data
- Universal AC input 90-264Vac
- Can be installed on DIN Rail TS-35/7.5/15
- Operating temperature -20°C to +70°C
- LED Indication for DC OK
- Dimension 40 x 125.2 x 113.5mm (W x H x D)
- 3 years warranty
- Manufacturer: MEAN WELL
Product specifications
| Output voltage (VDC) | 48 V |
| Manufacturer | MEAN WELL |
| Manufacturer warranty | 3 years |
| Product series | NDR |
| Overload characteristics | Constant current limiting |
| Certificates | EN62368-1 / ITE, UL508 |
| Depth | 113.5 mm |
| Height | 125.2 mm |
| Width | 40 mm |
| Input voltage range (VAC) | 90-264 V |
| Output current | 2.5 A |
| Power | 120 W |
| Efficiency | 89.00% |
Data sheets
Accessories
Related products
