About the product
NDR-120-12 is one economical slim 120W DIN Rail power supply,. The body is designed 40mm in width, which allows space saving inside the cabinets.
NDR-120 is designed with metal housing that enhances the unit’s power dissipation. With working efficiency up to 89%, the entire sereis can operate at the ambient temperature between -20°C and 70°C under air convection.
The complete protection functions and relevant certificates for industrial control apparatus (UL508c TUV BS EN62368-1 etc.) make NDR-120 a very competitive power supply solution for industrial applications.
Technical data
- Universal AC input 90-264Vac
- Can be installed on DIN Rail TS-35/7.5/15
- Operating temperature -20°C to +70°C
- LED Indication for DC OK
- Dimension 40 x 125.2 x 113.5mm (W x H x D)
- 3 years warranty
- Manufacturer: MEAN WELL
Product specifications
Output voltage (VDC) | 12 V |
Manufacturer | MEAN WELL |
Manufacturer warranty | 3 years |
Product series | NDR |
Overload characteristics | Constant current limiting |
Certificates | EN62368-1 / ITE, UL508 |
Depth | 113.5 mm |
Height | 125.2 mm |
Width | 40 mm |
Input voltage range (VAC) | 90-264 V |
Output current | 10 mA |
Power | 120 W |
Efficiency | 85.00% |
