120W DIN Rail Power Supply 12V/10A

Delivery at your place between May 21 and Jun 25 2025

Add to cart

About the product

NDR-120-12 is one economical slim 120W DIN Rail power supply,. The body is designed 40mm in width, which allows space saving inside the cabinets.

NDR-120 is designed with metal housing that enhances the unit’s power dissipation. With working efficiency up to 89%, the entire sereis can operate at the ambient temperature between -20°C and 70°C under air convection.
The complete protection functions and relevant certificates for industrial control apparatus (UL508c TUV BS EN62368-1 etc.) make NDR-120 a very competitive power supply solution for industrial applications.

Technical data

Universal AC input 90-264Vac
Can be installed on DIN Rail TS-35/7.5/15
Operating temperature -20°C to +70°C
LED Indication for DC OK
Dimension 40 x 125.2 x 113.5mm (W x H x D)
3 years warranty
Manufacturer: MEAN WELL

Product specifications

Output voltage (VDC)	12 V
Manufacturer	MEAN WELL
Manufacturer warranty	3 years
Product series	NDR
Overload characteristics	Constant current limiting
Certificates	EN62368-1 / ITE, UL508
Depth	113.5 mm
Height	125.2 mm
Width	40 mm
Input voltage range (VAC)	90-264 V
Output current	10 mA
Power	120 W
Efficiency	85.00%
