About the product
10W DC/DC-Converter, Input 43…160V, Output +/-5V / +/-1A
Technical data
- 10W Isolated Output
- Efficiency 88.5%
- Low No Load Power Consumption
- 4:1 Input Range
- Regulated Outputs
- Protection: Under Voltage/Over Current/Continuous Short Circuit
- Remote On/Off
- Railway standard EN50155 for Shock & Vibration
- Railway standard EN45545-2 for Fire & Smoke
- 3000m Operating Altitude
Product specifications
| Output voltage (VDC) | 5 V |
| Manufacturer | Cincon |
| Application | ITE/AV |
| Height | 11.7 mm |
| Width | 25.4 mm |
| Length | 25.4 mm |
| Package / case | 1x1 Inch |
| Additional functions | Remote ON/OFF |
| Regulation | Regulated |
| I/O isolation | 1500 V DC |
| Input voltage ratio | N/A |
| Input voltage range (VDC) | 43-160 V |
| Nominal input voltage (VDC) | 48-110 V |
| Output current | 1000 mA |
| Power | 10 W |
| Manufacturer warranty | 3 years |
